的主要用途与介绍/Brief Introduction：

该机型是转化成服食药液玻离瓶的新成品，充分处理好了一直以来服食药液玻离瓶的不良现象体验。这类灌封机所使用的金属瓶，虽然不是应该洗瓶机、晒干机，更不是应该进行消毒，会一直灌封。该机型全全自动流水线理瓶、进瓶、罐装生产线，罐装生产线量安稳，无漏滴，无瓶不罐装生产线。上盖、粘口率相当于100%。此机枝术现代化，空间小、开机运行安稳、背景噪声低，实操修理、除污非常方便等优缺点，可以满足GMP标准。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本型號有低转速和快速二者产出量供您决定。Note: this model has two kinds of low speed and high-speed production for your choice.

优点 Characteristic

◆机器支持于很多易折瓶口服方式液记量装灌和塑封。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆其他电嚣零件均用厂家厂家。All electrical components adopt famous brand◆该机操作方法形象直观简单，无瓶不灌装设备，计量校准*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑胶片瓶灌封机的主耍组成部分与方法Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型冲剂液易折塑瓶灌封机核心理瓶器、理盖器、主传动软件系统软件系统、导入带缝隙送单瓶置、玻璃瓶子检漏系统设计、罐装结构、排除系统设计、熔接封结构、气动系统机戒指尖夹瓶结构、伺服控制器同步电机缝隙上瓶结构与出瓶结构等组成的。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆广州POS机运用的口服方式液易折PVC瓶、盖都是定洁净并用区制造的，需要药粉材同意证，但是瓶身与底盖经引入和"去外包服务"后可会直接步入灌封间。按照理盖器、理瓶器的自动式定位分类整理，清除反向的方式给回底盖及瓶身底口朝下的瓶，使定位后的包材喂料有细则地步入传送发展轨道中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆方向后服食液易折塑料管瓶在传输在轨道总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

技木性能参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量超范围The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封膜率Hot sealing intensity	》99%
装量随机误差The load error	《1.5%
划伤率damage rate	《1.0%
额定功率power	2KW	3KW
电源适配器Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
自重 Weight	700Kg	800Kg
