适用范围与详细介绍/Brief Introduction：

全主动注塞泵式膏体酱罐电脑装机是属于我单位适应性销售市场实际需求的开发的新企业产品。机用户采取SUS304不锈钢装饰管注塞泵式计量检测泵实施罐装，且集主动上盖、主动旋盖、机电工程机电为一起，经济条件入门，土地征用空间小，多APP于药厂、肉制品、农药杀菌剂、化工类、化妆造型品等产业的介质设计，契合GMP规则标准。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

基本特征/characteristic：

◆选择齿轮泵式压力容器检验泵进行罐装，可用各种各样乳白色度液态体，精密度就越高；泵的架构选择快接式拆开组织机构，更加方便拆洗、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆液压泵式压力容器检验泵连杆环原料通过的行业及固态部分的有所差异选择硅塑胶，四氟氯乙烯或别的原料，特殊化的场所选择工业陶瓷原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调控系统化，变频柜变速，智能化限度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装生产线，自然运算基本功能。Lack of bottle filling, automatic counting function◆装量更改更方便，可是次更改都计算校准泵的充填量，也可重视各级计算校准泵完成微幅更改；操控简便方法，更改便捷。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆分装针头可设防漏滴装备，充填时突入瓶底分装，迟滞变高，控制气泡图片。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整个机械可选用区别技术参数的塑料瓶子，调节简便计算，可在多日间内完整。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆电脑整机按GMP追求设计。The machine designed according to the requirements of GMP

技术工艺性能参数/technic parameter：

适用于罐子外形尺寸Size of bottles	20-1000ml（只能根据需要订制）20-1000 - ml (according to your need）
用于瓶盖直经Apply the bottle diameter	¢20-¢150mm
适宜盖子规模Apply the lid specifications	¢20-¢70mm
生产制造力 production capacity	四头装灌：1000-2500瓶/每小时 Four filling head: 1000-2500 bottles per hour 八头包装：2500-4000瓶/小時 Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/天 12 head filling: 4000-6000 bottles per hour
装量数据误差The load error	±1%
旋盖良好率率Screw cover percent of pass	≥99%
电源模块power supply	380V，50HZ
马力power	3.0KW
供气gas sources	0.4-0.75MPA
时间抑制speed control	变频式调速器variable speed
